LUDO SPOT
LUDO SPOT is the innovative spot powered at 48V ideal for accent lighting or Wall Washer lighting. The originality of the design and the flexibility derived from the pivot points make it extremely versatile in any type of context. LUDO SPOT can only be used with low voltage tracks.
Technical features
Optics
Body
Legal References
Certifications
On Request
- Built-in driver
- 48V DC operation
- 3000K/4000K
- >95 lm/W
- CRI>90
- Eye safety: RG0/RG1
- Mac Adams 3
- L80/B10 >50.000h
- IP 40
- Direct emission
- LN PMMA lens 45° emission
- AS PMMA lens Wall Washer emission
Die-cast aluminum with epoxy powder coating.
In compliance with the safety standards EN 60 598-1
and UNI EN 12464-1 (lighting for working places).
- CE Conformity
- RETILAP Conformity
- Energy efficiency E
- 5 years warranty
- DALI – code D
- Bluetooth – code BT*
* Where available
Technical features
- Built-in driver
- 48V DC operation
- 3000K/4000K
- >95 lm/W
- CRI>90
- Eye safety: RG0/RG1
- Mac Adams 3
- L80/B10 >50.000h
- IP 40
Optics
- Direct emission
- LN PMMA lens 45° emission
- AS PMMA lens Wall Washer emission
Body
Die-cast aluminum with epoxy powder coating.
Legal References
In compliance with the safety standards EN 60 598-1
and UNI EN 12464-1 (lighting for working places).
Certifications
- CE Conformity
- RETILAP Conformity
- Energy efficiency E
- 5 years warranty
On Request
- DALI – code D
- Bluetooth – code BT*
* Where available
LUDO SPOT
versions
UGR<19
UGR<19 - wall washer
LUDO SPOT LN
LUDO SPOT
LUDO SPOT Download
TECHNICAL DRAWING
Optics
PMMA lens 45° emission.
Datasheets
4000K
code
flux
size
wiring
datasheet
specification items
20LN10K445
10W 4000K
950lm
129mm
Standard 48V
Dimmable 48V
Datasheets
3000K
code
flux
size
wiring
datasheet
specification items
20LN10K345
10W 3000K
855lm
129mm
Standard 48V
Dimmable 48V
LUDO SPOT AS
LUDO SPOT
LUDO SPOT Download
TECHNICAL DRAWING
Optics
PMMA lens for Wall Washer emission.
Datasheets
4000K
code
flux
size
wiring
datasheet
specification items
20AS10K4
10W 4000K
977lm
129mm
Standard 48V
Dimmable 48V
Datasheets
3000K
code
flux
size
wiring
datasheet
specification items
20AS10K3
10W 3000K
897lm
129mm
Standard 48V
Dimmable 48V
