REM
REM is a range of emergency fixtures with integrated driver and batteries up to 3-hour configurations. Mounting options include recessed installation, ceiling and for Esse-Ci three-phase track. The luminaires are equipped with 3 different types of lens, for anti-panic lighting, escape route or with an arrow beam for high ceiling applications.
Technical features
Optics
Body
Legal References
Certifications
On Request
- Integrated driver and accumulator
- Spot/escape routes/
- anti-panic
- 6500K
- 109 lm/W
- CRI >80
- Eye safety: RG0/RG1
- Mac Adams 3
- L80/B10 >50.000h
- IP 40
- Direct emission
Polycarbonate.
In compliance with the safety standards EN 60 598-1 and UNI EN 12464-1 (lighting for working places).
- CE Conformity
- 5 years warranty
- Always ON version
- Self-test
Technical features
- Integrated driver and accumulator
- Spot/escape routes/
- anti-panic
- 6500K
- 109 lm/W
- CRI >80
- Eye safety: RG0/RG1
- Mac Adams 3
- L80/B10 >50.000h
- IP 40
Optics
- Direct emission
Body
Polycarbonate.
Legal References
In compliance with the safety standards EN 60 598-1 and UNI EN 12464-1 (lighting for working places).
Certifications
- CE Conformity
- 5 years warranty
On Request
- Always ON version
- Self-test
REM
versions
REM Track
REM
TECHNICAL DRAWING
Optics
With Eutrack adaptor. 3 hours autonomy. With S/E mode (emergency only).
Datasheets
6500K
code
flux
size
wiring
datasheet
specification items
13EM2K65H3
2W 6500K
217lm
110x56mm
Standard
REM Ceiling Evo
REM
TECHNICAL DRAWING
Optics
For direct ceiling mount. 3 hours autonomy. With S/E mode (emergency only).
Datasheets
6500K
code
flux
size
wiring
datasheet
specification items
13EM2K65H3CE
2W 6500K
217lm
123x123mm
Standard
REM Recessed
REM
TECHNICAL DRAWING
Optics
For recessed mount. 3 hours autonomy. With S/E mode (emergency only).
Technical features
- Integrated driver and accumulator
- Spot/escape routes/
- anti-panic
- 109 lm/W
- CRI >80
- Eye safety: RG0/RG1
- Mac Adams 3
- L80/B10 >50.000h
- 5 years warranty
Datasheets
6500K
code
flux
size
wiring
datasheet
specification items
13EM2K65H3R
2W 6500K
217lm
Ø 51mm
Standard
