SEMPLICE LED
SEMPLICE LED is an innovative lighting solution suited to a wide range of interior applications including commercial, leisure and retail environments. Never before has a product been so versatile, with suspended or directly surface mounted versions available for wall and ceiling mounting. They can be installed individually, continuously mounted or even pattern formed using the tailored range of accessories. Its uniqueness is a scattered emitted light including the ends, thanks to the integrated LED technology and translucent end caps. A broad collection of matching products can be implemented for free standing and EU track mounting, giving the user continuity of product and complete design freedom in a project.
Technical features
Optics
Body
Legal references
Certifications
On request
- Integrated driver
- 3000K/4000K
- 90 lm/W
- CRI>90
- Eye safety: RG0/RG1
- Mac Adams 3
- L80/B20 >80.000h
- IP 40
- Direct/indirect emission
- PG optics for soft and homogeneous emission with no shadow areas
- EB optics for side emission
Shockproof, antistatic technopolymer with an exclusive paint treatment that guarantees a homogeneous “soft” emission over the entire surface. The ending and junction accessories are made of the same materials, with an invisible coupling fastening system
In compliance with the safety standards EN 60 598-1
and UNI EN 12464-1 (lighting for working places).
- CE Conformity
- RETILAP Conformity
- ETL Conformity
- Energy efficiency C
- 5 years warranty
- ETL certification
- DALI – code D*
- Emergency 1 hr – code EM*
- Emergency 3 hrs – code EM3H*
- 2700K – code K27*
- 5000K – code K5*
- Human Centric Lighting*
* Where available
Technical features
- Integrated driver
- 3000K/4000K
- 90 lm/W
- CRI>90
- Eye safety: RG0/RG1
- Mac Adams 3
- L80/B20 >80.000h
- IP 40
Optics
- Direct/indirect emission
- PG optics for soft and homogeneous emission with no shadow areas
- EB optics for side emission
Body
Shockproof, antistatic technopolymer with an exclusive paint treatment that guarantees a homogeneous “soft” emission over the entire surface. The ending and junction accessories are made of the same materials, with an invisible coupling fastening system
Legal references
In compliance with the safety standards EN 60 598-1
and UNI EN 12464-1 (lighting for working places).
Certifications
- CE Conformity
- RETILAP Conformity
- ETL Conformity
- Energy efficiency C
- 5 years warranty
- ETL certification
On request
- DALI – code D*
- Emergency 1 hr – code EM*
- Emergency 3 hrs – code EM3H*
- 2700K – code K27*
- 5000K – code K5*
- Human Centric Lighting*
* Where available
SEMPLICE LED
versions
suspended
track
SEMPLICE LED PG
SEMPLICE LED
SEMPLICE LED Download
TECHNICAL DRAWING
Optics
PMMA technopolymer (UGR<22) with surface treatment for completely uniform light distribution. Integrated LED technology.
Datasheets
4000K
code
flux
size
wiring
datasheet
specification items
67PG24K4HP
24W 4000K
2268lm
624mm
Standard
Dimmable
67PG36K4HP
36W 4000K
3402lm
904mm
Standard
Dimmable
Emergency
67PG48K4HP
48W 4000K
4536lm
1184mm
Standard
Dimmable
Emergency
67PG72K4HP
72W 4000K
6804lm
1744mm
Standard
Dimmable
Emergency
67PG108K4HP
108W 4000K
10206lm
2584mm
Standard
Dimmable
Emergency
Datasheets
3000K
code
flux
size
wiring
datasheet
specification items
67PG24K3HP
24W 3000K
2155lm
624mm
Standard
Dimmable
67PG36K3HP
36W 3000K
3232lm
904mm
Standard
Dimmable
Emergency
67PG48K3HP
48W 3000K
4309lm
1184mm
Standard
Dimmable
Emergency
67PG72K3HP
72W 3000K
6464lm
1744mm
Standard
Dimmable
Emergency
67PG108K3HP
108W 3000K
9696lm
2584mm
Standard
Dimmable
Emergency
SEMPLICE LED EB
SEMPLICE LED
SEMPLICE LED Download
TECHNICAL DRAWING
Optics
PMMA technopolymer (UGR<22) with surface treatment and super-pure aluminum reflector for bi-directional light distribution. Integrated LED technology.
Datasheets
4000K
code
flux
size
wiring
datasheet
specification items
67EB24K4HP
24W 4000K
2167lm
624mm
Standard
Dimmable
67EB36K4HP
36W 4000K
3251lm
904mm
Standard
Dimmable
Emergency
67EB48K4HP
48W 4000K
4334lm
1184mm
Standard
Dimmable
Emergency
67EB72K4HP
72W 4000K
6502lm
1744mm
Standard
Dimmable
Emergency
67EB108K4HP
108W 4000K
9752lm
2584mm
Standard
Dimmable
Emergency
Datasheets
3000K
code
flux
size
wiring
datasheet
specification items
67EB24K3HP
24W 3000K
2059lm
624mm
Standard
Dimmable
67EB36K3HP
36W 3000K
3088lm
904mm
Standard
Dimmable
Emergency
67EB48K3HP
48W 3000K
4118lm
1184mm
Standard
Dimmable
Emergency
67EB72K3HP
72W 3000K
6176lm
1744mm
Standard
Dimmable
Emergency
67EB108K3HP
108W 3000K
9265lm
2584mm
Standard
Dimmable
Emergency
SEMPLICE LED Eutrack
SEMPLICE LED
SEMPLICE LED Download
TECHNICAL DRAWING
Optics
PMMA technopolymer (UGR<22) with surface treatment for completely uniform light distribution. Integrated LED technology. Fitted with EU Track connector.
Datasheets
4000K
code
flux
size
wiring
datasheet
specification items
67PG24K4HPAB
24W 4000K
2268lm
624mm
Standard
Dimmable
67PG36K4HPAB
36W 4000K
3402lm
904mm
Standard
Dimmable
67PG48K4HPAB
48W 4000K
4536lm
1184mm
Standard
Dimmable
67PG72K4HPAB
72W 4000K
6804lm
1744mm
Standard
Dimmable
67PG108K4HPAB
108W 4000K
10206lm
2584mm
Standard
Dimmable
Datasheets
3000K
code
flux
size
wiring
datasheet
specification items
67PG24K3HPAB
24W 3000K
2155lm
624mm
Standard
Dimmable
67PG36K3HPAB
36W 3000K
3232lm
904mm
Standard
Dimmable
67PG48K3HPAB
48W 3000K
4309lm
1184mm
Standard
Dimmable
67PG72K3HPAB
72W 3000K
6464lm
1744mm
Standard
Dimmable
67PG108K3HPAB
108W 3000K
9696lm
2584mm
Standard
Dimmable
